70MHz Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-1072A-U
■ 70 MHz bandwidth, 2 input channels
■ 1 GSa/s real-time sampling rate, 25 GSa/s equivalent sampling rate
■ Up to 2M memory depth
■ Peak detection up to 10 ns
■ 15 sets of panel settings and waveform storage/retrieval
■ 5.7” TFT full-color display
■ 27 sets of automatic measurements
■ Horizontal sweep: 1nS ~ 50S/div
■ Supports USB Host and Device access
■ Go/NoGo testing functionality
■ Data logger
Out of Stock
Views: 585
Description
The GDS-1072A-U 70MHz Desktop Digital Oscilloscope utilizes MemoryPrime technology to optimize long memory capacity, allowing for the display of finer waveform variations and enhancing analysis efficiency. With a bandwidth of up to 70 MHz and two input channels, it is ideal for various testing needs in electronics engineering, research and development, and education, enabling users to easily capture and analyze signal waveforms.
Specifications
- Bandwidth70MHz
- Channels8 Bit
- Sampling Rate25G Sa/s
- Memory Depthless than 5ns
- Resolutionsingle channel reaches2M, dual channel 1M
- Rise Time２
- Input Impedance300V (DC+AC peak), CAT II
- Overload Protection± 3% full scale
- Trigger Accuracy1MΩ ±2%, ~15pF
Features
- Wave Trigger／ ／...
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
- Multi-language Interface15records
- Signal OutputUSB 2.0 full speed (CDC-ACM)
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
- Altitude LimitLower than 1,000 meters
- Power SupplyApprox. 18W, 40VA maximum
- Fuse1A slow, 250V
- Display5.7 inch, TFT, Brightness Adjustable
- Interface310(W) x 142(H) x 140(D) mm
- DimensionsApprox. 2500g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessoriesprobex2, probe,,,
