Arbitrary Waveform Function Generator
Brand
GWINSTEK
|
Model
AFG-3051
|
🇹🇼 Taiwan
Built-in multiple waveform outputs and sweep functions support sine, square, triangle, and arbitrary waveforms, flexibly meeting a wide range of testing needs.
Equipped with AM, FM, and PWM modulation functions, it enables more comprehensive signal simulation and analysis, making it widely applicable in R&D, education, and electronic testing.
Out of Stock
Views: 478
Description
The GWINSTEK AFG-3051 Arbitrary Waveform Function Generator offers a variety of waveform selections and high-resolution signal generation, making it suitable for communication, electronic testing, and research laboratories. This device supports standard and custom waveforms, providing a wide frequency range and high precision signal measurement to meet diverse application needs.
Specifications
- Waveformsupports,, standard and
- Sound Frequency1uHz ~ 50MHz, 1uHz ~ 50MHz, 1uHz ~ 1MHz
- Resolution1uHz
- Stable Performance±1 ppm (0°C ~ 50°C) / ±0.3 ppm (18°C ~ 28°C)
- memory1M, setsmax.memory 10
Features
- Sweep Functionsupports,,, /
- Modulation FunctionAM, FM, PWM, supports
- Safety RatingUSB, RS-232, GPIB
- Display4.3 inch TFT LCD, 480 × 272
Attributes
- Dimensions265 × 107 × 374 mm
- WeightApprox. 4 kg
- Operating Temperature0°C ~ 40°C
- Storage Temperature-10°C ~ 70°C
- Safety RatingUSB, RS-232, GPIB
- Display4.3
