100MHz 4-channel Desktop Digital Oscilloscope

Name: GWINSTEK GDS-1104B 100MHz 4-channel Desktop Digital Oscilloscope
Brand: GWINSTEK
SKU: GDS-1104B
Price: 33810 TWD
Availability: OutOfStock

Brand GWINSTEK | Model GDS-1104B | 🇹🇼 Taiwan

■ Four-channel input ■ 1GSa/s sampling rate ■ Maximum 10M memory depth per channel ■ 7-inch 800 x 480 WVGA LCD display ■ 256-level color display function ■ 1Mpts FFT frequency domain signal display ■ One-key zeroing setting ■ Sleek design, lightweight

Price NT$ 33,810

Out of Stock

The GDS-1104B is a 100MHz 4-channel desktop digital oscilloscope with a sampling rate of up to 1GSa/s and a maximum memory depth of 10M, capable of clearly displaying minute variations in complex waveforms. Its 7-inch 800 x 480 WVGA LCD screen, combined with a 256-level color display function, enhances the representation of waveforms, making it ideal for various electronic testing and troubleshooting applications, enabling engineers and technicians to quickly and accurately analyze signal characteristics.

Bandwidth100MHz
Channels4
Sampling Rate8 Bit
Memory Depth50,000 / s
Resolutionless than 3.5ns
Waveform Update Ratemax. 10Mpts
Rise Time300V (DC+AC peak), CAT II
Timebase Accuracy± 3% full scale
Input Impedance1MΩ ±2%, ~15pF
Overload Protection24 sets
Trigger Accuracy±3% full scale
Vertical Sensitivity-

Wave TriggerTraditional Chinese / Simplified Chinese / English, etc.
Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
Search and Navigation6digits, ±2％
Signal OutputUSB 2.0 High-speed host, USB High-speed 2.0, RJ-45, Go-NoGo BNC

Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
Altitude LimitLower than 1,000 meters
DisplayApprox. 18W, 40VA maximum
Power Supply1A slow, 250V
Fuse7“ TFT WVGA color display
Interface380 X 208 X 127.3 mm
DimensionsApprox. 2800g
WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
Accessoriesprobex2, probe,,,
