Linear DC Power Supply
Brand
GWINSTEK
|
Model
GPR-M
|
🇹🇼 Taiwan
The GPR-M series linear DC power supply employs advanced technology to deliver stable voltage and current regulation, with various voltage and current options to meet different application needs. Its measurement accuracy and low ripple design ensure the quality of testing in laboratories and production lines.
Out of Stock
Views: 525
Description
The GPR-M series offers continuously adjustable output voltage and current up to their rated values, featuring excellent regulation and fast transient response, suitable for high-precision applications.
GPR-1810HD 0 ~ 18V, 0 ~ 10 A
GPR-3060D 0 ~ 30V, 0 ~ 6 A
GPR-6030D 0 ~ 60V. 0 ~ 3A
Specifications
- Output VoltageOutput Voltage: 0 ~ 18V, 30V, 60V; Output Current: 0 ~ 10A, 6A, 3A
- Output CurrentLine Regulation < 0.01% + 3mV; Load Regulation <0.01% + 5mV (<10A), <0.02% + 5mV (>10A)
- Voltage Limit Regulation Rate< 1mVrms (5Hz ~ 1MHz)
- Voltage Load Regulation Rate< 100μS (50% load change, minimum load 0.5A)
- Current Limit Regulation RatePower Supply < 0.2% + 3mA
- Current Load Regulation Rate< 0.2% + 3mA
- Voltage Ripple< 1mVrms (5Hz ~ 1MHz)
- Response Time< 100μS (50%, min. 0.5A)
Features
- ChannelsLine Regulation < 0.2% + 3mA; Load Regulation <0.2% + 3mA
- Output ControlChassis & Terminal 20MΩ or above (DC 500V), Chassis & Power Cord 30MΩ or above (DC 500V)
- Operating ModeVoltage / Current
- Output Characteristicsand
- Overload Protectionand Protection
- Insulation Resistanceand 20MΩ (DC 500V), andPower Supply 30MΩ (DC 500V)
Attributes
- Display255(W) x 145(H) x 335(D) mm
- Power SupplyApprox. 11.5kg
- DimensionsAC 100V/120V/220V/240V±10%, 50/60Hz
- WeightUser Manual, Power Cord, Test Lead GTL-104
- Accessories, Power Supply, GTL-104
