Non-contact Phase Sequence Indicator
Brand
TECPEL
|
Model
PHS-864A
|
🇨🇳 China
The PHS-864A Non-contact Phase Sequence Indicator is suitable for live line inspections, simple electrical checks, phase loss judgment, and fault location.
- Electrostatic induction measurement principle
- Applicable wire diameter range: Φ10mm~40mm
- Safe operation without stripping or high voltage contact
- Automatic shutdown feature (approximately five minutes)
- LED dynamic display for ease of use
Price
NT$ 2,310
Out of Stock
Views: 590
Description
The PHS-864A Non-contact Phase Sequence Indicator is an efficient tool designed for industrial testing, featuring non-contact detection, phase loss judgment, and automatic shutdown functions. Its large clamp and LED display make the testing process safe and convenient, especially for live line inspections and simple electrical checks. With a measurement principle based on electrostatic induction, it accommodates wire diameters from Φ10mm to 40mm, ensuring safety and efficiency without the need for stripping or high voltage contact.
Specifications
- measurementinductance
- Specification70~1000VAC
- Sound Frequency45~65Hz
- Specification Φ10mm~40mm
- Auto Power Offapprox. min
- Low Battery IndicatorLED
- Power SupplyAA x 2
- Battery Lifeapprox.70hours
- Operating Temperature0℃~40℃, max. 80%
- Storage Temperature-10℃~50℃, max. 80%
- Accessories,,
- Dimensions70 x 75 x 30mm
- Weightapprox.200 g
Features
- Specificationyes
- Specification yes
- Auto Power Offyes
- Specification yes
- LED displayyes
Attributes
- Dimensions70(L) x 75(W) x 30(H) mm
- WeightApprox. 200g
- Operating Temperature0℃~40℃, Max Relative Humidity 80%
- Storage Temperature-10℃~50℃, Max Relative Humidity 80%
- AccessoriesApprox. 60cm
- Power SupplyAA Alkaline Batteries x 2
