32V 3A DC power supply
Brand
UNI-T
|
Model
UTP-3303-II
|
🇨🇳 China
Multi-channel power supply with dual-channel 32V/3A output and single-channel 5V/3A output. Its versatile output functions meet various needs. Lightweight, compact, and easy to carry, with a moderate price, it is an ideal choice for applications requiring low fluctuation.
Out of Stock
Views: 527
Description
The UTP3300 series are 3-channel linear DC power supplies with low ripple/noise, overload protection and constant voltage/current capabilities.
Parallel mode
When both the upper and lower buttons "light", it enters parallel mode. The positive terminal of CH1 is the parallel positive output terminal, and the negative terminal of CH1 is the parallel negative output terminal. The voltage and current value settings in parallel mode can only be adjusted through CH1. The total voltage value is equal to the voltage value of CH1, and the current value is equal to CH1+CH2
Specifications
- Output Voltage0~32V / 0~3A
- CH3 Output Range5V/3A
- Interface3 channels
- Constant Voltage Regulation≦0.01%+3mV
- Voltage Load Regulation Rate≦0.01% + 3mV (≦3A)
- Current Limit Regulation Rate≦0.2% + 3mA
- Current Load Regulation Rate≦0.2% + 3mA
Features
- Channels3 channels
- Display ModeDual display showing voltage and current simultaneously
- Operating ModeConstant voltage and current limiting modes
- Output CharacteristicsLow ripple and low noise
- Overload ProtectionOverload and reverse polarity protection
- Alarm FunctionCC and CV indicators stay lit
Attributes
- Operating Temperature0~40 °C / below80%RH non-condensing
- Storage Temperature-10~70 °C / below70%RH non-condensing
- Altitude Limitbelow 1,000 m
- Display3 digits LED display
- Accuracy±( 1% of rdg + 2 digits )
- Power SupplyAC 115V/230V ±10% , 50/60Hz
- Dimensions260(W) x 170(H) x 315(D) mm
- Weight9kg
- AccessoriesPower cord, test leads
