AC/DC Digital Clamp Meter
Brand
TECPEL
|
Model
DCM-043
|
🇹🇼 Taiwan
The DCM-043 Digital Clamp Meter offers the following features:
- Measurement range: 10~100 A (AC/DC)
- Automatic shutdown: 30 minutes
- Max/min value display
- Complies with IEC 1010 600V CAT II, 300V CAT II safety standards
Out of Stock
Views: 15
Description
The DCM-043 Digital Clamp Meter is a high-performance tool designed for measuring both AC and DC currents. With a minimum display of 0.001A, it allows for precise measurement of electrical currents in devices, making it suitable for electronics repair, appliance testing, and industrial applications. This clamp meter features an automatic shutdown function to extend battery life and a max/min value display, enabling users to monitor current variations effectively.
Specifications
- 精確度每秒 ２次
- 鉗口開度Ø12.5 mm
- 交流電流10~100 A <±(3.5% +10)>
- 直流電流10~100 A <±(4.5% +10)>
- 交流電壓600 V <±(1.5% +5)>
- 直流電壓600 V <±(1.0% +2)>
- 電阻10K Ω <±(1.0% +3)>
- 解析度DC: 0.1V / AC: 0.1V
Features
- 自動關機30分鐘
- 最大/最小值10 mV/Amp
- 訊號輸出IEC 1010 600V CAT II, 300V CAT II
Attributes
- Operating Temperature0~50°C / lower than 85%RH without dew。
- Storage Temperature-10~50°C / lower than 75%RH without dew。
- Elevation LimitationLower than 1,000 meters
- Power Supply1.5v Battery (AA) x 2
- Dimensions202 × 50 × 29 mm
- Weight180g (Battery including)
- AccessoryBattery x2、Test Lead、 Carrying Bag、Manual
