70MHz 4-channel Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-1074B
■ Four-channel input
■ 1GSa/s sampling rate
■ Maximum 10M memory depth per channel
■ 7-inch 800 x 480 WVGA LCD display
■ 256-level color display function enhances waveform representation
■ 1Mpts FFT frequency domain signal display
■ One-key zero setting
■ Innovative design, lightweight
Price
NT$ 30,450
Out of Stock
Views: 624
Description
The GDS-1074B 70MHz 4-channel Desktop Digital Oscilloscope is designed for efficient waveform analysis. This series optimizes memory size and display resolution, allowing for clear visualization of waveform details to meet various testing needs. Whether for electronic engineers or academic researchers, the GDS-1074B provides accurate test data and reliable performance, enabling seamless application in diverse environments.
Specifications
- Bandwidth70MHz
- Channels4
- Sampling Rate8 Bit
- Memory Depth50,000 / s
- Resolutionless than 5ns
- Waveform Update Ratemax. 10Mpts
- Rise Time300V (DC+AC peak), CAT II
- Timebase Accuracy± 3% full scale
- Input Impedance1MΩ ±2%, ~15pF
- Overload Protection24 sets
- Trigger Accuracy±3% full scale
- Vertical Sensitivity-
Features
- Wave TriggerTraditional Chinese / Simplified Chinese / English, etc.
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/Overshoot, Fall Preshoot/Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, - Width, Duty Cycle
- Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
- Search and Navigation6digits, ±2%
- Signal OutputUSB 2.0 High-speed host, USB High-speed 2.0, RJ-45, Go-NoGo BNC
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
- Altitude LimitLower than 1,000 meters
- DisplayApprox. 18W, 40VA maximum
- Power Supply1A slow, 250V
- Fuse7“ TFT WVGA color display
- Interface380 X 208 X 127.3 mm
- DimensionsApprox. 2800g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessoriesprobex2, probe,,,
