200MHz 2-channel Desktop Digital Oscilloscope
Brand
GWINSTEK
|
Model
GDS-2202E
200MHz bandwidth, 2 channels
■ 1GSa/s real-time sampling rate per channel
■ Standard 10M maximum memory depth and VPO waveform display technology
■ Waveform update rate up to 120,000 times/second
■ 8” WVGA TFT LCD display
■ Up to 1M points FFT for higher frequency domain resolution
■ High-pass and low-pass digital filter functionality
■ 29,000 segment memory and waveform search function
■ I2C/SPI/UART/CAN/LIN serial bus triggering and decoding
■ Data logging capability for tracking signal changes for up to 100 hours
■ Remote network storage support
Out of Stock
Views: 623
Description
The GDS-2202E 200MHz 2-channel desktop digital oscilloscope features a real-time sampling rate of 1GSa/s per channel and an 8-inch 800*480 TFT LCD display, allowing for clear visualization of complex and weak waveforms. With a minimum vertical scale of 1mV/div, this oscilloscope is suitable for various precision measurement applications, providing a waveform update rate of up to 120,000 times per second for rapid signal capture and analysis.
Specifications
- Bandwidth200MHz
- Channels2
- Sampling Rate8 Bit
- Memory Depth120,000 / s
- Resolutionless than 1.75ns
- Waveform Update Ratemax. 10Mpts
- Rise Time300Vrms, CAT I
- Timebase Accuracy± 3% full scale
- Input Impedanceapprox. 1MΩ// 16pF.
- Overload Protection24 sets
- Trigger Accuracy±3% full scale
- Vertical Sensitivity-
Features
- Wave Trigger／ ／...
- Waveform StorageVpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/ Overshoot
- Auto MeasurementFreq, Period, Rise Time, Fall Time, + Width, – Width, Duty Cycle
- Multi-language InterfaceCH1, CH2, CH3*, CH4*, Line, EXT
- Search and Navigation6digits, ±2％
- SpecificationUSB 2.0 , Ethernet(RJ-45), Go-NoGo BNC, Kensington Style Lock
Attributes
- Operating Temperature0~50°C / Below 80%RH @35°C, no condensation
- Storage Temperature-20~60°C / Below 70%RH @35°C, no condensation
- Altitude LimitLower than 1,000 meters
- DisplayApprox. 18W, 40VA maximum
- Power Supply1A slow, 250V
- Fuse7“ TFT WVGA color display
- Interface384 X 208 X127.3 mm
- DimensionsApprox. 2800g
- WeightOscilloscope probe x2, oscilloscope probe adjustment tool, transmission line, Disc, manual
- Accessoriesprobex2, probe,,,
