GWINSTEK LCR-8200A High Frequency LCR Meter
Brand
GWINSTEK
|
Model
LCR-8200A
|
🇹🇼 Taiwan
High-frequency benchtop LCR meter series for precise inductance, capacitance, resistance and impedance measurements.
Out of Stock
Views: 334
Specifications
- display7" LCD display (800x480)
- measurementFrequency LCR-8250A, 10Hz~50MHz. 6 digits, ±0.0007%
- Frequency LCR-8230ADC, 10Hz~30MHz; 6 Digits, ±0.0007%
- Frequency LCR-8220ADC, 10Hz~20MHz; 6 Digits, ±0.0007%
- Frequency LCR-8210ADC, 10Hz~10MHz; 6 Digits, ±0.0007%
- Frequency LCR-8205ADC, 10Hz~5MHz; 6 Digits, ±0.0007%
- Frequency LCR-8201DC, 10Hz~1MHz; 6 Digits, ±0.0007%
- Output Impedance25Ω / 100Ω optional
- Signal OutputVoltage: Current: DCRVoltage: 10mV ~ 2Vrms (Frequency. ≤ 1MHz), 10mV ~ 1Vrms (Frequency. > 1MHz orFrequency. ≤ 1MHz RO=25Ω) 100μA ~ 20mArms (RO=100Ω), 200μA ~ 40mArms (RO=25Ω) 1Vdc(max. 40mA)
- BASIC ACCURACY±0.08%
- Test Speedmax.: 2.5ms(>10kHz),: 50ms(>20Hz),: 100ms: 300ms, 2: 600ms
- measurementmeasurement::: 15 Freq/Vac/Iac/DC Bias/Comp/BIN,,
- measurement measurement display (Z), inductance (Ls / Lp), capacitance (Cs / Cp), resistance (Rs / Rp), (Q), (D), (Y), (G), (X), (θd / θr), (B), resistance(Rdc)
Features
- measurement:: measurement Freq/Vac/Iac/BIAS V,
- type ( “A” )7 type. type 4 typesets, type type.
- Other Functions(ALC)::: standard 0～±12V, and OK, NG or BIN 1-9
- Specification: V/I:::: / / / Voltage, Voltage, Voltage, Voltage, Δ, Δ %,, 1 to 64
Attributes
- Operating Environment0 ~ 40°C / below75%RH non-condensing
- Storage Environment5 ~ 40°C / below85%RH non-condensing
- Warm-up Time60min
- Power SupplyAC 100V ~ 240V, 50/60H
- Power ConsumptionMax 65VA
- Dimensions346 (W) X 145 (H) X 335 (D) mm;
- Weightapprox.3.3kg
